- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: b635-04
Chinese manufacturing precision quality small planer planer professional manufacturer of high quality assurance
Huashuo Product Spec
The maximum length of planing
350mm
Ram underside to table the maximum distance
330mm
Maximum table moving distance (horizontal)
400mm
Maximum table moving distance (vertical)
270mm
Planer to a maximum distance of bed leading face extending
550mm
The maximum displacement of the ram
170mm
Maximum table rotation angle (no vices)
Plus or minus 90 degrees
Maximum table rotation angle (with Vise)
Plus or minus 55 degrees
Turret maximum vertical stroke
110mm
Reciprocating ram per minute
32, 50, 80, 125, times min
When a tooth wheeled round (vertical)
0.18mm
Pillow slip back and forth once wheeled table feed wheel when a tooth (horizontal)
0.21mm
When the wheel rotates four teeth (vertical)
0.73mm
When the wheel rotates four teeth (horizontal)
0.84mm
Electric motor
1.5kw 1400r / min
Box size
1530 * 930 * 1370mm
Net / Gross
1000kg / 1200kg
- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: b635-04
Quick Details
| Condition: | New | Place of Origin: | Shandong China (Mainland) | Brand Name: | HSHUASHUO |
| Model Number: | b635-04 | Voltage: | 380 | Power(W): | 1500 |
| Dimension(L*W*H): | 150*930*1370 | Weight: | 1200 | Certification: | iso9001 |
| Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas | The appearance of color: | Can be customized |
| Working stroke: | Can be customized |
