- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: 4h
4h Turret Milling Machine/Rocker milling machine
Huashuo Product Spec
Shaft horsepower hp 3HP
Spindle speed rpm 66-45409 (16 speed)
Spindle taper R-8
Spindle tilt angle of 45 degrees (front) .90 degrees (about)
Cantilevered rotation angle of 360 degrees
Table size 1270 × 254mm
Table travel X to 750 (manual maximum 850) mm /
y to 400mm / z to 400mm
T-slot table specification 3/16/65
Spindle center to surface distance rail 155-635mm
Spindle nose to table distance 0-460mm
Maximum load 350kg
Machine weight 1250kg
Dimensions 1600 × 1700 × 2250mm
- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: 4h
| Condition: | New | Place of Origin: | Shandong China (Mainland) | Brand Name: | HSHUASHUO |
| Model Number: | 4h | Type: | Vertical | CNC or Not: | Normal |
| Voltage: | 380 | Power(W): | 2238 | Dimension(L*W*H): | 1600*1700*2300 |
| Weight: | 1250 | Certification: | is09001 | Warranty: | Two years |
| After-sales Service Provided: | Engineers available to service machinery overseas | Color: | Customizable | Dimensions: | Customizable |
