- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: z3045*14
z3045*14 Radial drilling machine/Metal drilling machine
Huashuo Product Spec
Maximum drilling diameter mm 45
Spindle nose to table distance mm 260-1150
Spindle center distance bus distance mm 360-1400 column
Optional spindle travel mm 300
Spindle taper (Morse) 4
Spindle speed range r.p.m 28.-. 1200
spindle speeds 12
Spindle Feed range r.p.m 0.10-0.25
Spindle feed rate series 3
Rocker rotation angle of 360
Main motor power kw 3
Lifting motor power kw 1.5
Machine weight kg 1700
Dimensions mm 1850 × 840 × 2300
- Place of Origin: Shandong, China (Mainland)
- Brand Name: huashuoCNC
- Model Number: z3045*14
| Condition: | New | CNC or Not: | Normal | Drilling Speed: | 28-1220r/mm |
| Place of Origin: | Shandong China (Mainland) | Brand Name: | HSHUASHUO | Model Number: | z3045*14 |
| Voltage: | 380v | Power(W): | 3000w | Dimension(L*W*H): | Length 1850mm width 850mm high 2300mm |
| Weight: | 1760 | Certification: | iso9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
| Color: | Customizable | Stroke Specifications: | Customizable |
